Radial spherical plain bearings SIL30ES

Bearing number : SIL30ES

Brand : SKF

Bore Diameter (mm) : 30

Bearing dimensions and specification in SKF catalogue:

d - 30 mm

d2 - 75 mm

d4 - 42 mm

dk - 40,7 mm

h1 - 110 mm

l3 min. - 45 mm

l4 max. - 149 mm

l5 - 19 mm

l7 min. - 34 mm

r1 min. - 0,6 mm

B - 22 mm

C1 max - 20 mm

w - 36 Tolerance h14

Thread (G) - M30x2 Tolerance 6H

Angle - 6 °

Weight - 1 Kg

Basic dynamic load rating (C) - 62 kN

Basic static load rating (C0) - 116 kN
