Concentra bearing units SYNT 90 FW

Bearing number : SYNT 90 FW

Size (mm) : 90x110x86

Brand : SKF

Bore Diameter (mm) : 90

Outer Diameter (mm) : 110

Width (mm) : 86

Bearing dimensions and specification in SKF catalogue:

da - 90 mm

A - 110 mm

B - 86 mm

H - 216 mm

H1 - 112 mm

H2 - 40 mm

J - 320 mm

L - 380 mm

H - 32 mm

N1 - 26 mm

J6 - 355 mm

J7 - 40 mm

N4 - max. - 8 mm

Basic dynamic load rating - C - 325 kN

Basic static load rating - C0 - 375 kN

Fatigue load limit - Pu - 39 kN

Limiting speed - 2100 r/min

Calculation factor - e - 0.24

Calculation factor - Y1 - 2.8

Calculation factor - Y2 - 4.2

Diameter - dm - 125 mm

Basic Designation bearing - 22218 E

Pa - 35 kN

P0° - 470 kN

P55° - 620 kN

P90° - 370 kN

P120° - 280 kN

P150° - 250 kN

P180° - 310 kN

Mass bearing unit - 21 kg

Diameter - G - 24 mm
