Concentra bearing units SYR 1 1/2

Bearing number : SYR 1 1/2

Size (mm) : 38.1x62.706x53.975

Brand : SKF

Bore Diameter (mm) : 38,1

Outer Diameter (mm) : 62,706

Width (mm) : 53,975

Bearing dimensions and specification in SKF catalogue:

da - 38.1 mm

d2 - 62.706 mm

A - 53.975 mm

A1 - 72.231 mm

B - 69.85 mm

H - 100.012 mm

H1 - 47.625 mm

H2 - 30.162 mm

L - 174.625 mm

J - max. - 139.7 mm

J - min. - 119.062 mm

s - 25.4 mm

S - 0.794 mm

Basic dynamic load rating - C - 73.8 kN

Limiting speed - 5100 r/min

Mass bearing unit - 3.15 kg
