Concentra bearing units SYR 2 1/2 N

Bearing number : SYR 2 1/2 N

Size (mm) : 63.5x68.262x65.484

Brand : SKF

Bore Diameter (mm) : 63,5

Outer Diameter (mm) : 68,262

Width (mm) : 65,484

Bearing dimensions and specification in SKF catalogue:

da - 63.5 mm

A - 68.262 mm

B - 65.484 mm

H - 142.875 mm

H1 - 69.85 mm

H2 - 44.45 mm

L - 234.95 mm

J - max. - 196.85 mm

J - min. - 173.038 mm

s - 32.941 mm

S - 0.794 mm

Basic dynamic load rating - C - 193 kN

Limiting speed - 3100 r/min

Mass bearing unit - 7.26 kg
