Concentra bearing units SYR 2 15/16 N-118

Bearing number : SYR 2 15/16 N-118

Size (mm) : 68,262x74,612x65,484

Brand : SKF

Bore Diameter (mm) : 68,262

Outer Diameter (mm) : 74,612

Width (mm) : 65,484

Bearing dimensions and specification in SKF catalogue:

da - 74.612 mm

A - 68.262 mm

B - 65.484 mm

H - 165.894 mm

H1 - 82.55 mm

H2 - 57.15 mm

L - 265.112 mm

J - max. - 223.838 mm

J - min. - 198.438 mm

s - 32.941 mm

S - 0.794 mm

Basic dynamic load rating - C - 212 kN

Limiting speed - 3400 r/min

Mass bearing unit - 9.53 kg
