Concentra bearing units SYR 2 7/16-18

Bearing number : SYR 2 7/16-18

Size (mm) : 61.912x101.6x68.262

Brand : SKF

Bore Diameter (mm) : 61,912

Outer Diameter (mm) : 101,6

Width (mm) : 68,262

Bearing dimensions and specification in SKF catalogue:

da - 61.912 mm

d2 - 101.6 mm

A - 68.262 mm

A1 - 88.9 mm

B - 85.725 mm

H - 142.875 mm

H1 - 69.85 mm

H2 - 44.45 mm

L - 234.95 mm

J - max. - 196.85 mm

J - min. - 173.038 mm

s - 31.75 mm

S - 0.794 mm

Basic dynamic load rating - C - 148 kN

Limiting speed - 3800 r/min

Mass bearing unit - 7.26 kg
