Concentra bearing units SYNT 100 LTS

Bearing number : SYNT 100 LTS

Size (mm) : 100x120x86

Brand : SKF

Bore Diameter (mm) : 100

Outer Diameter (mm) : 120

Width (mm) : 86

Bearing dimensions and specification in SKF catalogue:

da - 100 mm

A - 120 mm

B - 86 mm

H - 238 mm

H1 - 125 mm

H2 - 45 mm

J - 350 mm

L - 410 mm

H - 32 mm

N1 - 26 mm

S - 2.5 mm

J6 - 385 mm

J7 - 45 mm

N4 - max. - 8 mm

Basic dynamic load rating - C - 425 kN

Basic static load rating - C0 - 490 kN

Fatigue load limit - Pu - 49 kN

Limiting speed - 2500 r/min

Calculation factor - e - 0.24

Calculation factor - Y1 - 2.8

Calculation factor - Y2 - 4.2

Diameter - dm - 140 mm

Basic Designation bearing - 22220 E

Pa - 35 kN

P0° - 600 kN

P55° - 680 kN

P90° - 410 kN

P120° - 310 kN

P150° - 275 kN

P180° - 340 kN

Mass bearing unit - 26 kg

Diameter - G - 24 mm
